IDEC MICROSmart FC6A-C24R1CE User Manual

1: G ENERAL I NFORMATION
1-2 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
HMI module
Cartridge base module
Digital I/O modules
*1 24V DC for products with a version number lower than V400. For details on the version number of modules, see "Checking the Version Number"
on page 2-1.
FC6A -
PH 1
Interface specification
1: Communication connector
Module type
PH: HMI module
FC6A -
HPH1
Module type
HPH1: Cartridge base module
FC6A -
M08BR1
Output type
R: Relay output (Mixed I/O module only)
K: Transistor sink output
P: Transistor protection source output
None: No output
Input type
A1: 120V AC
B: 12/24V DC
*1
None: No input
Terminal specification
1: Removable terminal block (Screw)
3: MIL connector
4: Removable terminal block (Push-in)
I/O points
08: 8 I/O points
16: 16 I/O points
24: 24 I/O points
32: 32 I/O points
Module type
N: Digital input module
R: Digital output module (Relay output)
T: Digital output module (Transistor output)
M: Digital mixed I/O module

IDEC MICROSmart FC6A-C24R1CE Specifications

General

Brand	IDEC
Model	MICROSmart FC6A-C24R1CE
Category	Computer Hardware
Language	English
