FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 2-125
2: P RODUCT S PECIFICATIONS
■ FC6A-L06A1, FC6A-L06A4
For wiring precautions, see "Input/Output Wiring" on page 3-18.
Screw fastened type: FC6A-L06A1 Push-in type: FC6A-L06A4
Applicable connector: FC6A-PMTC10PN02 Applicable connector: FC6A-PMSC10PN02
PWR
ANALOG
FC6A-L06A1
NC I3- I3+ NC I2- I2+ NC I1- I1+ NC NC I0- I0+ Q1- Q1+ Q0- Q0+ 0V 24V
PWR
ANALOG
FC6A-L06A4
NC I3- I3+ NC I2- I2+ NC I1- I1+ NC NC I0- I0+ Q1- Q1+ Q0- Q0+ 0V 24V
: Fuse
0V
24V
FE
24V DC
Q0+
Q0-
OUT0
Q1+
Q1-
OUT1
I1+
I1-
NC
I0+
I0-
NC
IN0
IN1
I2+
I2-
NC NC
IN2
I3+
I3-
NC NC
IN3
NC
NC
NC NC
Terminal No. I/O
+
-
Analog Voltage/
current Input Device
+
-
Analog Voltage/
current Input Device
+
-
+
-
Analog Voltage/
current Output Device
+
-
Analog Voltage/
current Output Device
- +
Analog Voltage/
current Output Device
2-wire Analog Output Sensor
- +
