2: P RODUCT S PECIFICATIONS
2-192 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
Expansion
interface module
FC6A-EXM1M
55°C - -
65°C - -
FC6A-EXM1S
55°C - -
65°C - -
FC6A-EXM1S4
55°C - -
65°C - -
FC6A-EXM2
55°C - -
65°C - -
FC6A-EXM24
55°C - -
65°C - -
Communication
module
FC6A-SIF52
55°C - -
65°C - -
FC6A-SIF524
55°C - -
65°C - -
FC6B series
FC6B-D16K1C
55°C
8 inputs: 24V DC,
Input 0, 1, 6, 7: 5mA/PT
Others : 7 mA/PT
Tota l Max. 28.8 mA
8 transistor sink outputs:
24V DC, 0.5 A/PT resistive
Total Max. 3.2 A, Limited energy
65°C
8 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others : 7 mA/PT
Tota l Max. 10 mA, 2 PTs
8 transistor sink outputs:
24V DC, 0.5 A/PT resistive
Total Max. 1 A, 2 PTs, Limited energy
FC6B-D16K4C
55°C
8 inputs: 24V DC,
Input 0, 1, 6, 7: 5mA/PT
Others : 7 mA/PT
Tota l Max. 28.8 mA
8 transistor sink outputs:
24V DC, 0.5 A/PT resistive
Total Max. 3.2 A, Limited energy
65°C
8 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others : 7 mA/PT
Tota l Max. 10 mA, 2 PTs
8 transistor sink outputs:
24V DC, 0.5 A/PT resistive
Total Max. 1 A, 2 PTs, Limited energy
FC6B-D16P1C
55°C
8 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others : 7 mA/PT
Tota l Max. 28.8 mA
8 transistor source outputs:
24V DC, 0.5 A/PT resistive
Total Max. 3.2 A, Limited energy
65°C
8 inputs: 24V DC,
Input 0, 1, 6, 7: 5mA/PT
Others : 7 mA/PT
Tota l Max. 10 mA, 2 PTs
8 transistor source outputs:
24V DC, 0.5 A/PT resistive
Total Max. 1 A, 2 PTs, Limited energy
FC6B-D16P4C
55°C
8 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others : 7 mA/PT
Tota l Max. 28.8 mA
8 transistor source outputs:
24V DC, 0.5 A/PT resistive
Total Max. 3.2 A, Limited energy
65°C
8 inputs: 24V DC,
Input 0, 1, 6, 7: 5mA/PT
Others : 7 mA/PT
Tota l Max. 10 mA, 2 PTs
8 transistor source outputs:
24V DC, 0.5 A/PT resistive
Total Max. 1 A, 2 PTs, Limited energy
FC6B-D16R1C
55°C
8 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others : 7 mA/PT
8 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES), 7 A (Common)
D300, 2 A 30V AC, 180 VA 120/240V AC, R300, 1 A
30V DC, 28 VA 125/250V DC pilot duty
65°C
8 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others : 7 mA/PT
Tota l Max. 24 mA, 4 PTs
8 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES), 7 A (Common)
D300, 2 A 30V AC, 180 VA 120/240V AC, R300, 1 A
30V DC, 28 VA 125/250V DC pilot duty
Total Max. 8 A, 4 PTs
FC6B-D16R4C
55°C
8 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others : 7 mA/PT
8 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES), 7 A (Common)
D300, 2 A 30V AC, 180 VA 120/240V AC, R300, 1 A
30V DC, 28 VA 125/250V DC pilot duty
65°C
8 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others : 7 mA/PT
Tota l Max. 24 mA, 4 PTs
8 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES), 7 A (Common)
D300, 2 A 30V AC, 180 VA 120/240V AC, R300, 1 A
30V DC, 28 VA 125/250V DC pilot duty
Total Max. 8 A, 4 PTs
Model Names Type Air Temp Inputs Outputs
