FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 3-47
3: I NSTALLATION AND W IRING
*1 For the wires that can be used, see "Wiring the CAN J1939 Bus" on page 3-52.
■ Plus CPU module
Screwdriver
SZS 0.4×2.5 (1205037)
SDS 0.4X2.5X75 (9009030000)
―― ―
SZS 0.6×3.5 (1205053)
SDS 0.6X3.5X100 (9008330000)
Yes Yes Yes
Tightening torque (N) 0.51 0.51 0.51
CPU Module Terminals Power Supply Terminals
Input Terminals/Output
Terminals (FC6A-D16R1CEE,
FC6A-D16K1CEE, FC6A-
D16P1CEE, FC6A-D16R4CEE,
FC6A-D16K4CEE, FC6A-
D16P4CEE only)
Wire Type
UL1007
UL2464
Equivalent
UL1015
Equivalent
UL1007
UL2464
Equivalent
UL1015
Equivalent
Stripping length (mm) 7 9
Wire thickness (mm
2
) 0.2 to 2.5 0.14 to 1.50
Wire
gauge
AWG 24
1-wire
usage
AI 0,25- 6 (3203040)
H0,25/10 HBL (9025740000)
Yes ―――
AI 0,25- 8 (3203037)
H0,25/12T GE (9021020000)
Yes ― Yes ―
AI 0,25-10 (3241128)
―
――Yes ―
AWG22
1-wire
usage
AI 0,34- 6 (3203053)
H0,34/10 TK (9025750000)
Yes ―――
AI 0,34- 8 (3203066)
H0,34/12 TK (9025770000)
Yes ― Yes ―
AI 0,34-10 (3241129)
―
――Yes ―
AWG20
1-wire
usage
AI 0,5- 6 (3200687)
H0,5/12D W (9019000000)
Yes ―――
AI 0,5- 8 (3200014)
H0,5/14D W (9019010000)
Yes ― Yes ―
AI 0,5- 8 GB (1208966)
―
― Yes ― Yes
AI 0,5-10 (3201275)
H0,5/16D W (9019020000)
――Yes ―
AI 0,5-10 GB (3203150)
H0,5/16 DS W (9202910000)
―――Yes
2-wire
usage
AI-TWIN 2 x 0,5-8 (3200933)
H0,5/14D ZH W (9037380000)
Yes ―――
AI-TWIN 2 x 0,5-10 (3203309)
H0,5/16D ZH W (9037390000)
――Yes ―
AWG18
1-wire
usage
AI 0,75- 6 (3200690)
H0,75/12D GR (9019030000)
Yes ―――
AI 0,75- 8 (3200519)
H0,75/14D GR (9019040000)
Yes ―――
AI 0,75-10 (3201288)
H0,75/16D GR (9019050000)
――――
AI 1-8 (3200030)
H1,0/14D R (9019080000)
― Yes ――
AI 1-10 (3200182)
H1,0/16D R (9019100000)
――――
2-wire
usage
AI-TWIN 2 x 0,75-8 (3200807)
H0,75/14D ZH GR (9037410000)
Yes ―――
AI-TWIN 2 x 0,75-10 (3200975)
H0,75/16D ZH GR (9037420000)
――――
CPU Module Terminals
Power Supply
Terminals
Input Terminals
Output Terminals
CAN Port
(CAN J1939 All-in-One
CPU module only)
Wire Type
UL1007
UL2464
Equivalent
UL1015
Equivalent
UL1007
UL2464
Equivalent
UL1015
Equivalent
UL1007
UL2464
Equivalent
*1
UL1015
Equivalent
*1
