7: HMI F UNCTION
7-30 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
Configuring the Blinking Speed
The blinking speed for messages displayed with the message (MSG) instruction can be configured.
These settings can be configured when the user program is stopped. This cannot be configured while the user program is running.
1. On the standard screen, press the (ESC) + (OK) buttons.
The system menu is displayed.
2. Select Configurations with the (up) and (down) buttons and press the (OK) button.
3. Select Function with the (up) and (down) buttons and press the (OK) button.
4. Select Message Settings with the (up) and (down) buttons and press the (OK) button.
5. Select Blink Settings with the (up) and (down) buttons and press the (OK) button.
6. Select Blinking Speed with the (up) and (down) buttons and press the (OK) button.
7. Modify the value with the (up) and (down) buttons and press the (OK) button. For example, change the value to 1,000 ms.
 Selectable blinking speeds
The blinking speeds that can be selected are as follows.
500/600/700/800/900/1000 ms
Stopped
2015/DEC/01/TUE
13:30:40
Run
Edit Program
External Memory
Configurations
Function
Clock
Menu Languages
Backlight
Communications
Message Settings
Scroll Settings
Blink Settings
Blinking Speed:
500 ms
Blinking Speed:
1000 ms
