7: HMI F UNCTION
7-34 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
Modifying a Word Device Value
This section describes an example of changing D0002 to 500 while the user program is running.
1. On the standard screen, press the (ESC) + (OK) buttons.
The system menu is displayed.
2. Select Device Monitor with the (up) and (down) buttons and press the (OK) button.
The FC6A Series MICROSmart switches to the Device Monitor mode.
3. Select device type: D (Data Register) with the (left) and (right) buttons and press and hold the (OK) button.
4. Select D0002 with the (up) and (down) buttons and press the (OK) button.
5. Move the digit with the (right) button and modify the value with the (up) and (down) buttons.
6. Press the (OK) button to confirm.
Running
13:30:40
2015/DEC/01/TUE
Stop
External Memory
Device Monitor
Status Monitor
D
D
D
D
000000:
00001:
00002:
00003:
0
0
0
D000000:
00001:
00002:
00003:
D0
D0
D0
Change Device Val.:
D 00002:
00500
DEC (W)
'
'
'
'
000000:
00001:
00002:
00003:
0
500
0
