7: HMI F
UNCTION
7-42 FC6A S
ERIES
MICROS
MART
U
SER
’
S
M
ANUAL
FC9Y-B1722
Format SD memory card with the FC6A Series MICROSmart
The SD memory card inserted into the CPU module is formatted using the HMI module buttons. In order to save the log data,
format the SD memory card with the CPU module.
The SD memory card can be formatted when the user program is stopped. The SD memory card cannot be formatted when the
user program is running.
1. On the standard screen, press the (ESC) + (OK) buttons.
The system menu is displayed.
2. Select External Memory with the (up) and (down) buttons and press the (OK) button.
3. Select SD Card with the (up) and (down) buttons and press the (OK) button.
4. Select Format with the (up) and (down) buttons and press the (OK) button.
5. Select Yes with the (down) button and press the (OK) button.
6. While the SD memory card is being formatted, the screen below is displayed. When the format is finished, the screen in step 4
is displayed.
Stopped
2015/DEC/01/TUE
13:30:40
Run
Edit Program
External Memory
Configurations
Stop Access
Format
Recipe
Program
Do you want to
format SD card?
No
Yes
