Operating Ranges
The operating range of Type 1 (IEC 61131-2) DC input modules is as follows.
Input Internal Circuit
Transition
Area
ON Area
I0, I1, I6, I7
OFF Area
1.5 mA
8 mA
Input Current (mA)
2.4 V
5.6 V
12 V
Input Voltage (V DC)
18 V
0.2 mA 5 mA
Transition
Area
ON Area
I2 to I5, I10 to I27
OFF Area
2.3 mA
8.5 mA
Input Current (mA)
2.4 V
5.6 V
12 V
Input Voltage (V DC)
18 V
0.6 mA 6 mA
2.0 kΩ
I0, I1, I6, I7
Input
COM
Internal Circuit
2.0 kΩ
I2 to I5, I10 to I27
Input
COM
Internal Circuit
