FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 2-45
2: P RODUCT S PECIFICATIONS
Applicable connector
(2) Input terminals
DC Sink Input Wiring
DC Source Input Wiring
40-I/O Type: Screw fastened type: FC6A-C40R1DE, FC6A-C40K1DE, FC6A-C40P1DE, FC6A-C40R1DEJ,
FC6A-C40K1DEJ, FC6A-C40P1DEJ
Push-in type: FC6A-C40R4DE, FC6A-C40K4DE, FC6A-C40P4DE, FC6A-C40R4DEJ,
FC6A-C40K4DEJ, FC6A-C40P4DEJ
(1) Power supply terminals
Screw fastened type FC6A-PMTD03PN02
Push-in type (12 VDC) FC6A-PMSDD03PN02
(2) Sensor power terminals, input terminals
Screw fastened type FC6A-PMTA09PN02
Push-in type FC6A-PMSA09PN02
(3) Output terminals
Screw fastened type FC6A-PMTA10PN02
Push-in type FC6A-PMSA10PN02
Screw fastened type Push-in type (1) Power supply
terminals
(2)
(3)
(1)
(2)
(3)
(1)
: Fuse
: Load
L
12V DC Power Input
+12V - FE
- +
External Power
12V DC
NC. NC. COM I0 I1 I2 I3 I4 I5 I6 I7
I10 I11 I12 I13 I14 I15 I16 I17 I20 I21 I22 I23 I24 I25 I26 I27
– 12V DC Input 12V DC Input 12V DC Input
-
+
-
+
External Power
12V DC
2-wire
Sensor
NC.
NC. COM
I0 I1 I2 I3 I4 I5
I6
I7 I10 I11 I12 I13 I14 I15 I16 I17 I20 I21 I22 I23 I24 I25 I26 I27
– 12V DC Input 12V DC Input 12V DC Input
+
-
+
-
External Power
12V DC
2-wire
Sensor
