IDEC SA1U Series - Background Suppression

Long sensing range of 50m maximum (through-beam type)
Universal voltage and DC power types available for worldwide usage
SA1U
Terminal
Block Type
Photoelectric Switches
IDEC’s original spring-up screw
terminal block saves wiring time
Washdown IP67 Environment
Four Sensing Methods
Time Delay
Various Mounting Hole Layouts
Universal Voltage Power Supply
Ideal for use in a wet enviroment such as bottling and food
processing lines.
Four operation modes to choose from: one shot, ON delay,
OFF delay, and normal modes.
Time ranges can be set from 0.1 to 5 seconds.
Universal voltage types operate on 24 to 240V AC and
12 to 240V DC. DC power types operate on 12 to 24V DC.
Mounting hole centers are selectable from 40, 50 to 55 mm.
Long distance detection. Offers sensing range of up to 50m.
Sensing range up to 2m. Not affected by background.
Sensing range up to 7m. Easily detects mirrored surfaces.
Sensing range up to 1m. Detects objects that reflect light,
even transparent objects.
Background suppresion
Polarized-retroreflective
Spring-up screw terminal block
enables easy wiring. Save up to
65% wiring time compared
to competitor products
(IDEC research).
IDEC’s unique spring-up screw
terminal block∗ is used
.
∗The screw is normally in the lifted position,
ready for wiring. No need to loosen or
remove screws, improving work
efficiency. Screws are held
captive.
Spring-Up Screw Te rminal Block
IP67 Waterproof Protection
Easy Wiring
Operation status can be
easily recognized by LEDs
Recognizable from different
directions. The front side is
visible from a distance.
Sensitivity of through-beam
types can easily be
adjusted.
Close Mounting (except through-beam)
Interference prevention enables close mounting
of two SA1U photoelectric switches in limited spaces.
Diffuse-reflective
Through-beam
Suitable for detecting
the object.
The background
is not detected.
Ideal for use in large
facilities such as
automatic parking lots.
Polarized
Retroreflective
Through
Beam
Background
Suppression
Diffuse
Reflective
Easily detects objects
that absorb light and
mirror surface objects
Detects objects that reflect light,
even transparent objects.
Maximum sensing range:
50m
Maximum sensing range: 2m
Maximum sensing range: 1m
Maximum sensing range:
7m
50m
The longest sensing
range in the industry
50m maximum
1m maximum
7m maximum
2m maximum
Object
Object
Object
Object
Reflector
2
Stable LED
*
Power LED for through-beam type
Status LED
Note: IP67 protection degree is acheived when an applicable cable is used.
