Idegis DOMOTIC SERIES User Manual

28
9. TECHNICAL CHARACTERISTICS: ______________________________________________________________________________
TECHNICAL SPECIFICATIONS:
Standard working voltage
230V AC – 50/60 Hz.
Cable: 3 x 1.0 mm
2
, leng. 2 m.
Domotic Series 12 0.8 A
Domotic Series 24 1.1 A
Domotic Series 32 1.5 A
Domotic Series 42 1.5 A
Fuse
Domotic Series 12 2A T (5x20 mm)
Domotic Series 24 3.15A T (5x20 mm)
Domotic Series 32 4A T (5x20 mm)
Domotic Series 42 4A T (5x20 mm)
Output voltage
8 – 9 V DC (24 V DC DOM-40)
Cable 3 x 4 mm
2
, leng. 2 m.
Domotic Series 12 12 A (2x6 A)
Domotic Series 24 24 A (2x12 A)
Domotic Series 32 32 A (2x16 A)
Domotic Series 42 42 A (6x7 A)
Production
Domotic Series 12 10 – 12 g./h.
Domotic Series 24 20 – 24 g./h.
Domotic Series 32 25 – 32 g./h.
Domotic Series 42 34 - 42 g./h.
Minimum recirculation flow
Domotic Series 12 2 m
3
/h.
Domotic Series 24 4 m
3
/h.
Domotic Series 32 6 m
3
/h.
Domotic Series 42 8 m
3
/h.
Electrode number
Domotic Series 12 5
Domotic Series 24 7
Domotic Series 32 7
Domotic Series 42 13
Net weight (packaging included)
Domotic Series 12 11 Kg.
Domotic Series 24 13 Kg.
Domotic Series 32 15 Kg.
Domotic Series 42 17 Kg.
GENERAL FEATURES:
Control system
 Microprocessor.
 Membrane keypad with control keys and operation
indication leds.
 Control I/O: 3 inputs (potential-free contact type) for
monitoring the external flow switch, the state of the
automatic cover and ORP/residual chlorine controller.
 Cell output: production control (11 discrete levels).
Integrated pH controller (only DOM –XX PH and DOM-
XX PLUS).
 Integrated ORP controller.
(only in DOM-XX PLUS models).
Self-cleaning
Automatic polarity switch
Working temperature
From 0
°
C (32°F) to +40°C (104°F)
Cooling: natural convection
Material
Power supply / wall terminal
o ABS
Electrolysis cell and sensor-holder
o Transparent methacrylate
pH sensor (DOM-XXPH and DOM-XX PLUS)
Body: plastic (blue)
Range 0 -12 pH
Solid electrolyte
ORP sensor (DOM-XX PLUS models)
Body: plastic (red)
Range 0 – 1000 mV
Solid electrolyte
