i-MARK 2 / i-MARK 3
USER MANUAL
VISIBILITY DELIVERED. PAGE 46 OF 55
Marker Loops at Stock Places or Parking Lots
 Several loops in close proximity to each other
 i-MARKs not connected via i-BUS (not synchronized)
 Tags remain in the marker loop field
The standard setting will be:
 Adjust the size of the inductive loop field with the loop current
 Give every i-MARK a unique Loop ID
 Leave Operation mode to “Continuous”
 Set a cycle delay
 Enable Jitter
 Select several or all slots
Active loop 1
Slot #
1 2 3 4 5 6 7 8 9 10 11 12 1 2 3 4 5 6 7 8 9 10 11 12
Active loop 2
Slot #
1 2 3 4 5 6 7 8 9 10 11 12 1 2 3 4 5 6 7 8 9 10 11 12
