Page 8 / 11
Rev.: 1105 / VP
e. Remove Clip from the fitting.
f. Pull out the stem of the fitting from filter by press the collet
g. Unscrew the cap from membrane housing.
h. Place membrane into the housing and push by hand until appropriate
location.
3. Select a location for the equipment. Be sure that there is space underneath to
installation and tubing.
4. Install water supply valve: The feed water valve is included with system. Install
a valve on the cold water supply pipe. Thread the white tubing onto the valve-
adapter.
5. Install drain adapter: it is designed to fit 40 mm sink drain pipe.
6. Install faucet: Select a location for the faucet. If drilling is needed, make a 12
mm diameter hole.
: Be sure to turn off the water supply and open a low faucet to
drain the pipe.
To Next Page
