7.2. Detection Area
The 862-01-CX-702RSC has a variety of option detection area options. You can select
Wide Angle detection or Long Range detection. You can also adjust the vertical angle
according to your desired detection range.
To select either Wide Angle or Long Range detection, remove the lens holder from the
detector, and change the orientation of the lens. There are markings to indicate which
detection type you have chosen. A “W” will show on top of the lens for Wide Angle, and
an “L” will show on top of the lens for Long Range.
