IDS Optex Xwave

Dip Switch
Dip Switch 1 - Walk Test Mode
Position
Function
ON
Test Mode On. The LED lights irrespective of the Dip switch 4 setting.
Dip switch 2, Battery Saving Timer, is inactive.
OFF
Normal Mode. LED and Battery Saving Timer works according to
their setting.
NB: Once the walk test is complete always set the detector to Normal Mode. Using the
detector in Test Mode will shorten the battery life.
Dip Switch 2 – Battery Saving Timer
Position
Function
ON
Even if there are continuous alarms, the alarm is only generated once
in a 5 second time.
OFF
Even if there are continuous alarms, the alarm is only generated once
in a 120 second time. To lengthen battery life.
Dip Switch 3 – Alarm & Trouble Output
Position
Function
ON
Sets the alarm type to Normally Open (N.O.)
OFF
Sets the alarm type to Normally Closed (N.C.)
NB: This settings must be set to ON, or Anti-Masking and Tamper conditions will not be sent
from the Wireless Transmitter.
Dip Switch 4 - LED
Position
Function
ON
Enables the LED.
OFF
Disables the LED. To lengthen battery life.
Dip Switch 5 – Anti-Masking (RAM & RDAM Only)
Position
Function
ON
Enables anti-masking. A trouble is generated after 20 seconds of
masking.
OFF
Disables anti-masking. A trouble is generated after 3 minutes of
masking.
NB: Be careful not to leave any objects within 1 metre of the detector. Anti-Masking is sent as a
tamper to the X-Series Panel.
Dip Switch 6 – Microwave Immunity (RDAM Only)
Position
Function
ON
Microwave Immunity logic is activated. Use this setting in harsher
environments, such as moving trees or bushes.
OFF
Microwave Immunity logic is deactivated.
