IDS Optex Xwave - FTN Series Dip Switch Functions

Dip Switch 2 – Battery Saving Timer
Position
Function
ON
Even if there are continuous alarms, the alarm is only generated once
in a 5 second time.
OFF
Even if there are continuous alarms, the alarm is only generated once
in a 120 second time. To lengthen battery life.
Dip Switch 3 – Trouble Output
Position
Function
ON
Sets the output type to Normally Open (N.O.)
OFF
Sets the output type to Normally Closed (N.C.)
NB: This setting must be set to ON, or Anti-Masking will not be sent from the Wireless
Transmitter. Anti-Masking is sent as a tamper to the X-Series Panel.
Dip Switch 4 - LED
Position
Function
ON
Enables the LED.
OFF
Disables the LED. To lengthen battery life.
Dip Switch 5 – PIR Sensitivity
Position
Function
ON
Normal PIR sensitivity.
OFF
Low PIR sensitivity.
Dip Switch 6 – Not Used
LEDs
Warm-up – Red LED blinks for approximately 120 seconds
Alarm Condition – Red LED turns on for 2 seconds
Masking Detection (862-01-FTN-RAM Only) – Red LED blinks 3 times and then repeats
