IDS Optex Xwave

Dip Switch
1/2 – Beam Interruption
3 – Battery Saving Timer
4 – Intermittent Output
5 – N.O/N.C Output
Alarm LED Indicator
AX Series Receiver
Low Battery
LED Indicator
View Finder
Horizontal
Alignment Dial
Vertical
Alignment Dial
Voltage Monitor
Jack
Tamper Switch
Supervision Jumper
J1 On – 90 mins
J1 Off – 12 hrs
IDS Wireless
Transmitter
Power Connector
Connect the battery
holder lead here.
Detector Inputs
Tamper & PIR inputs
come from the
detector.
Battery Holder
Holds 2 x LSH 20
batteries
Tamper Switch
Beam Frequency
Selection
