Pulse Count is the amount of times the detector needs to be triggered within a 20
second period before an alarm condition is sent.
When the 862-01-WNX-40PI-T detector is in Normal Operation it will only send an alarm
after a wait period of 120 seconds from the last alarm condition.
LEDs
Warm-up – Red LED blinks for approximately 60 seconds
Alarm – Red LED turns on for 2 seconds
4.2. Detection Area
The 862-01-WNX-40PI-T has a detection range of up to 12 metres at an 85° angle.
Top view of detection area
Side view of detection area
