Section 3
SPECIFICATION
VersaKey Keyboard
Mechanical
Keyswitch
Total Travel 4.0 + 0.5 mm
Operating Force 50 + 7g
Keyboard
Color Black
Size 469.9 mm (L) x 203.9 mm (W) x 42.8 mm (H)
Material High Impact PS, Meets flammability spec. UL94HB
Cable Information
Jacket Material PVC jacket with Aluminum Shielding
Length 1.5 M (5ft.) Overall
PC Connector USB
Drop 610 mm (24”) Drop: 1 corner, 2-sidelines, 3-sides
Vibration 60 Hz/sec 3 mm amplitude X, Y and Z each axis at
two hours
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 40°C (- 4°F to 104°F)
Electrical
Power Requirement +5.0 VDC ±10%, 60ma Max
Industry Requirements FCC class B and CE
Reliability
Operating Life 20,000,000 keystrokes
ESD Immunity 0KV to 8 kV min, without data loss.
8KV to 15 kV min, will function after reset
MTBF More than 60,000 hours
MagStripe Reader
Number of tracks Tracks 1 & 2 or Tracks 2 & 3 or Tracks 1, 2 & 3
Compatibility ISO 7810 and 7811-1 through -6 cards.
Communications Decoded data sent through Keyboard
communications cable.
Output data formatting Default or customized data output format;
programmable through PC configuration utility. See
Appendix for defaults
Operating Life 1,000,000 card swipes
Card speed range 3 to 60 IPS (Inches Per Second)
Audio beeper Indicates error free card data reading or not
