G-11c/GCG-11c

Instruction Manual

STARTUP, OPERATION AND TEMPERATURE ADJUSTMENT

Operation

•Priortostockingcoolerwithproduct,itshouldbeoperatedemptyforhalfanhour.

Temperature Adjustment

Lit Door “Logo” Switch

Operation

•Thelightswitchlocatedatthebottomlefthandsideontherearofthe

cabinetistheON/OFFswitchfortheLitlogolocatedonthedoorofcooler.

REPAIR AND MAINTENANCE FOR REFRIGERATION DRAWER

* A CERTIFIED TECHNICIAN IS REQUIRED TO REPAIR ALL REFRIGERATION COMPONENTS

FOR WARRANTY PURPOSES.

Forconvenientrepair,therefrigerationcomponents(compressor,evaporator,condenser,

evaporationfan,condensationfanandlter)aredesignedusingasplit

system;anycomponentcanbeeasilyreplaced.Replacementprocedureis

asfollows:

1 Unplugtheunit.

2 Removethescrewsfromthefrontgrill,andthenremovethegrill.

3 Unplugallconnectionsandterminalsthatareinneedofrepair.

•G-11c/GCG-11cperformancetestingpositionofthethermostatisaround4.5-6.

4 Usingascrewdriver,removescrews

fromrefrigerationdrawer.

5 SlidetheRefrigerationDrawerouttoeasilyaccess

refrigerationcomponents.Removethecomponenttoreplaceorrepair.

6 Afterrepair,re-installallpartsusingthereverseprocedure.

4 Page9

REPLACING THE CANOPY LIGHT

1UnscrewtheGraphicsHolderontheLeftHandSideoftheTopCanopy

2CarefullyslideouttheentireGraphicspiece.

6ToinstallLEDlightparts,followtheabovedirectionsinreverseorder.

3DisconnecttheLEDlightwiring.

5RemoveLEDlightparts.

4PullouttheLEDlightpartsfromthetwoclips.

109

IDW G-11-C33EB-HC User Manual
