IDW G-11-C33EB-HC User Manual

Innovative DisplayWorks
G-11c/GCG-11c
Instruction Manual
CONDENSER MAINTENANCE
Itisessentialtokeepthecondensercoilscleanandfreeofdustanddebrisatalltimes.Itisrequiredto
periodicallycleanthecondensercoilswithasoftbristlebrushorvacuum-cleanertoproperly
maintaintherefrigerationsystem.Failuretocleanthecondenseratregularintervalsmay
causefailureoftherefrigerationsystemandcouldvoidthewarranty.
1 Removetherubbercapfromthefrontgrill.
2UsingasmallPhillipsheadscrewdriver,removethethreescrewsas
shown.
3Thefrontplasticgrillcannowberemovedbypullingitup.

4Usingplasticbristlebrush,carefullycleanthecoilbeingawarethatcoilscan
bendorbedamagediftoomuchforceisused-shownleft.
5ReplacegrillandutilizethePhillipsscrewdrivertotightenthescrewsintoplace,
replacetherubbercaps.
CANOPY GRAPHICS REPLACEMENT
1 UnscrewtheGraphicsHolderontheLeftHandSideoftheTopCanopy
2 CarefullyslideouttheentireGraphicspiece.
3 ReplacewithanewGraphicspiece.
4 CarefullyinsertandslideinthenewGraphicspiece.
5 FixtheGraphicsHolderbyfasteningthescrew.
SETTING UP SPACER & POWER CORD HOLDERS
TheG-11c/GCG-11cissuppliedwithoneset(2pieces)ofSpacerstohold
theextralengthofPowerCord(showninpicturebelow)
1TakeoutthetwoSpacersandscrewssuppliedinthe
AccessoryPackshippedwiththeCooler.
2UseaPhilipsscrewdrivertoxthetwoSpacersat
positionsasshowninpicturebelow.
1211
MAINTENANCE
Cleaning
• Unplug the cooler before cleaning.
• Use a soft cloth or sponge with water or soap (non-corrosive mild detergent). After cleaning, wipe the cooler using a
dry cloth to prevent the cooler from rusting.
• Do not spray water on the cooler, and do not use hard or steel brushes to clean the cooler.
• Do not use organic solvents, boiling water, washing powders or acids while cleaning.
• A drain or waste outlet may be provided for the draining of a display refrigerator. If the display refrigerator drains are
provided for fl ushing, they shall have a minimum internal diameter of 1˝ (25mm).
If the cooler will be in a non-operational state for a long period of time, clean as
instructed above, and keep the door open until interior is dry.
