Innovative DisplayWorks, Inc.
Instruction Manual
10 11
G-26c/GCG-26c
SETTING UP SPACERS & POWER CORD HOLDERS
These coolers are supplied with one set (2 pieces) of Spacers to hold the extra length of Power Cord.
START-UP, OPERATION AND TEMPERATURE ADJUSTMENT
Operation
Prior to stocking cooler with product, it should be operated empty for half an hour.
Temperature Adjustment
Switch Operation for Lit Door Logo
Button for Changing Motion Logo Modes
1 Take out the two Spacers
and Screws supplied in the
Accessory Pack shipped with
the Cooler.
Performance tested position of
the thermostat is between 4-6.
For GCG coolers only. The light switch
located at the bottom left hand side,
on the rear of the cabinet, is the ON/
OFF switch for the Lit logo located on
the door of cooler.
2 Use a Phillips screwdriver to
secure the two Spacers onto
the rear of the cooler.
Mode 1: The logo lights are permanently lit and do not
sequence.
Mode 2: The logo lights sequence showing the bottle
emptying and fl ashing full. This is the default setting.
Please Note: When replacing the controller, remove four (4)
screws on the rear cover plate to gain access.
MAINTENANCE
Condenser
It is essential to keep the condenser coils clean and free of dust and debris at all times. It is required
to periodically clean the condenser coils with a soft bristle brush or vacuum-cleaner to properly
maintain the refrigeration system. Failure to clean the condenser at regular intervals may cause
failure of the refrigeration system and could void the warranty.
Cleaning
• Unplug the cooler before cleaning.
• Use a soft cloth or sponge with soap and water (non-corrosive mild detergent), while cleaning.
After cleaning, wipe the cooler using a dry cloth to prevent the cooler from rusting.
• Do not spray water on the cooler, and do not use hard or steel brushes to clean the cooler.
• Do not use organic solvents, boiling water, scrubbing powders or acids while cleaning.
• A drain or waste outlet may be provided for draining of a display refrigerator. If a display
refrigerator drain is provided for fl ushing, it will have a minimum internal diameter of 1” (25mm)
If the cooler will be in a non-operational state for a long period of time, clean as instructed above,
and keep the door open until interior is dry.
2 Using a small Phillips head
screwdriver and remove the
screws as shown.
1 Remove the rubber cap
from the front grill.
3 The front grill can now be
removed by pulling it up.
4 Using plastic bristle brush,
carefully clean the condenser
being aware that coils can
bend or be damaged if too
much force is used.
5 Replace grill and use the
Phillips screwdriver to
tighten the screws into
place, replace the rubber
caps.
To Next Page
