IEI Technology WAFER-JL-N5105 Quick Installation Guide

10
39
GND
40
N/C
41
PCIE_RXN0
42
N/C
43
PCIE_RXP0
44
N/C
45
GND
46
N/C
47
PCIE_TXN0
48
N/C
49
PCIE_TXP0
50
PERST#
51
GND
52
CLKREQ#
53
REFCLKN
54
PEWAKE
55
REFCLKP
56
N/C
57
GND
58
N/C
59
N/C
60
N/C
61
N/C
62
N/C
63
N/C
64
N/C
65
N/C
66
N/C
67
WWAN_RST
68
N/C
69
PEDET
70
+3.3V
71
GND
72
+3.3V
73
GND
74
+3.3V
75
CONFIG_2
M2_A1: M.2 A-key Slot
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
2
+V3.3A
3
USB+
4
+V3.3A
5
USB-
6
NC
7
GND
8
Module Key
9
Module Key
10
Module Key
11
Module Key
12
Module Key
13
Module Key
14
Module Key
15
Module Key
16
NC
17
NC
18
GND
19
NC
20
NC
21
NC
22
NC
23
GND
24
GND
