IEI Technology WAFER-JL-N5105 Quick Installation Guide

9
JSPI1: Flash SPI ROM Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
+3.3V
2
SPI_CS#
3
SPI_SO
4
SPI_CLK
5
SPI_SI
6
GND
USB2_CN1: Internal USB 2.0 Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
VCC
2
GND
3
USB_DATA-
4
USB_DATA+
5
USB_DATA+
6
USB_DATA-
7
GND
8
VCC
M2_1: M.2 B-key Slot
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
CONFIG_3
2
+3.3V
3
GND
4
+3.3V
5
GND
6
POWER_OFF
7
USB_D+
8
W_DISABLE
9
USB_D-
10
DAS/DSS#
11
GND
12
Module Key
13
Module Key
14
Module Key
15
Module Key
16
Module Key
17
Module Key
18
Module Key
19
Module Key
20
N/C
21
CONFIG_0
22
N/C
23
N/C
24
N/C
25
N/C
26
GNSS_DISABLE
27
GND
28
N/C
29
PCIE_RXN1
30
UIM_RST
31
PCIE_RXP1
32
UIM_CLK
33
GND
34
UIM_DATA
35
PCIE_TXN1
36
UIM_VCC
37
PCIE_TXP1
38
DEVSLP
