IEI Technology WAFER-JL-N5105 Quick Installation Guide

8
RST_BTN1: Reset Button Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
Reset+
2
Reset-
PWR_BTN1: Power Button Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
PWR_BTN+
2
PWR_BTN-
COM1, COM2: RS-232 Serial Port Connectors
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
DCD
2
DSR
3
RXD
4
RST
5
TXD
6
CTS
7
DTR
8
RI
9
GND
SATA1: SATA 6Gb/s Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
5
SATA_RX‐
2
SATA_TX+
6
SATA RX+
3
SATA_TX‐
7
GND
4
GND
8
N/C
SATA_PWR1: SATA Power Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
+5V
2
GND
I2C1: SMBus Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
3
SMB_CLK
2
SMB_DATA
4
+5V
