4 Electrical connection
The unit must be connected by a qualified electrician�
The national and international regulations for the installation of electrical
equipment must be adhered to�
Voltage supply to EN 50178, SELV, PELV
Disconnectpower.
Connecttheunitasfollows:




 




 
A:SI5002;SI0521(positiveswitching);B:SI5003(negativeswitching)
Corecoloursofifmsockets:
1=BN(brown),2=WH(white),3=BU(blue),4=BK(black)
5 Operating and display elements





1: Operation display
•ThegreenLEDsindicatethecurrentflow(theLEDs0to9representtherangebetween
no flow and maximum flow)�
•TwoLEDsindicatethepositionoftheswitchpoints(orange=outputclosed,red=output
open)�
2, 3: Setting buttons for adjustment and configuration
