IO-Link Master with Modbus TCP Interface DataLine 4 Ports IP 65 / IP 66 / IP 67
34
>
9.1.10 IO-Link ports: Set the device validation and data storage
33697
The user can choose how the IO-Link ports are to behave with regard to the device validation and the
storage / recovery of parameter data of the connected IO-Link device.
The following options are available:
Option
Validation of the IO-Link
device
Storage of the parameter values
Recovery of the parameter
values
[No check and clear]
no
no
no
[Type compatible
V1.0 device]
yes, test the compatibility with
IO-Link standard V1.0
no
no
[Type compatible
V1.1 device]
yes, test the compatibility with
IO-Link standard V1.1
no
no
[Type compatible
V1.1 device with
Backup + Restore]
yes, test the compatibility with
IO-Link standard V1.1 and
identity of design (vendor ID
and device ID)
yes, automatic storage of the
parameter values; changes of the
current parameter values will be
stored
yes, recovery of the parameter
values when connecting an
identical IO-Link device with
factory settings
[Type compatible
V1.1 device with
Restore]
yes, test the compatibility with
IO-Link standard V1.1 and
identity of design (vendor ID
and device ID)
no, there is no automatic storage
changes of the current parameter
values will not be stored
yes, recovery of the parameter
values when connecting an
identical IO-Link device with
factory settings
The options only apply if the IO-Link port is in the operating mode "IO-Link".
For options [Type compatible V1.1 device with Backup + Restore] and [Type compatible V1.1
device with Restore]: If the vendor ID and device ID are changed in the online mode, the data
memory will be deleted and a new backup of the parameter values of the connected IO-Link
device will be created in the IO-Link master.
To configure the device validation and the data storage:
► select [Port x] menu (x = 1...4).
> The menu page shows the current settings.
► Set the following parameters as required:
Name
Description
Possible values
[Validation / Data
Storage]
Supported IO-Link standard and behaviour of the
IO-Link master when connecting a new IO-Link
device at port x (x = 1...4)
[No check and clear]
[Type compatible V1.0
device]
[Type compatible V1.1
device]
[Type compatible V1.1 device
with Backup + Restore]
[Type compatible V1.1 device
with Restore]
[Vendor ID]
ID of the manufacturer that is to be validated
0...65535
Factory setting: 0#
ifm electronic: 310
[Device ID]
ID of the IO-Link device that is to be validated
0...16777215
Factory setting: 0
► Save changed values on the device.
>
