IFM AL1340 - Page 35

IO-Link Master with Modbus TCP Interface DataLine 4 Ports IP 65 / IP 66 / IP 67
35
9.1.11 IO-Link ports: set fail-safe values
34459
In case the Modbus TCP connection is interrupted, fail-safe values can be assigned to the outputs of
the IO-Link ports.
To set the fail-safe values of the IO-Link ports:
► Select [Port x] menu (x = 1...4).
> The menu page shows the current settings.
► Set the following parameters as required:
Name
Description
Possible values
[Fail-safe digital out]
Fail-safe values for output (operating mode "DO")
Reset
Reset value (LOW)
Old
hold old value
Set
Set value (HIGH)
[Fail-safe IO-Link]
Fail-safe value for output (operating mode "IO-Link")
Off
no fail-safe value
Reset
reset value
Old
hold old value
Pattern
provide sample
► Save changed values on the device.
>
9.1.12 Info: Show device information
34065
To read the general information of the ifm IO-Link master:
► Select [Info] menu.
> The menu page shows the current settings.
Name
Description
Possible values
[Product code]
Article number of the IO-Link master
AL1340
[Device family]
Device family of the IO-Link master
IO-Link master
[Vendor]
Vendor
ifm electronic gmbh
[SW-Revision]
Firmware of the IO-Link master
[HW revision]
Hardware version of the IO-Link master
[Bootloader revision]
Bootloader version of the IO-Link master
[Serial number]
Serial number
