9.2.5 Configure the fieldbus interface
34476
Via the fieldbus interface (ports X21 / X22) the AL1340 will be integrated in the Modbus TCP network.
Substructure: fieldbussetup
Available data points:
Last name
Description
Access
../fieldbusfirmware
Firmware version of the IO-Link master
r
../network/macaddress
MAC address of the fieldbus port
r
../network/ipaddress
IP address of the fieldbus port
rw*
../network/subnetmask
Subnet mask of the network segment
rw*
../netowrk/ipdefaultgateway
IP address of the network gateway
rw*
../network/dhcp
Activate/deactivate the DHCP client of the device
rw
../connectionstatus
Status of the connection to the Modbus TCP network
r
../configuration/processdataconfiguration
Length of the process input data and process output data
rw*
../configuration/connectiontimeout
max. value for fieldbus connection timeout
rw*
../configuration/swap
Arrangement of the bytes
rw*
./configuration/port[n]/failsafedigitalout
Fail-safe value for the digital output - pin 4 (DO)
rw*
../configuration/port[n]/failsafeiolink
Fail-safe value for output data IO-Link
rw*
n ... 1...4
r ... read only
rw ... read and write
* ... parameter only editable, if connection to Modbus TCP plc is interupted
Applicable services:
Name
Description
../network/setblock
write all values of substructur at once
