IFM AL1340 - Page 45

IO-Link Master with Modbus TCP Interface DataLine 4 Ports IP 65 / IP 66 / IP 67
45
>
9.2.6 Configure IO-Link ports
52248
The user can configure the IO-Link ports X01...X04 separately.
Substructure: iolinkmaster/port[n] (n = 1...4).
Available data points:
Name
Description
Access
../senddatatosmob
Send process data to LR SMARTOBSERVER
rw*
../mastercycletime_preset
Cycle time of the data transfer at the IO-Link port (value in microseconds)
rw
../mastercycletime_actual
Current cycle time of the data transfer at the IO-Link port (value in
microseconds)
r
../portevent
Activity display
rw
../mode
Operating mode of the IO-Link port
rw*
../comspeed
Data transfer rate of the IO-Link port
rw
../validation_datastorage_mode
Response of the IO-Link port when a new IO-Link device is connected
rw*
../validation_vendorid
IO-Link ID of the manufacturer that is to be validated
rw*
../validation_deviceid
IO-Link ID of the device that is to be validated
rw*
../datastorage
Data storage area of the port
rw
../datastorage/maxsize
Maximum size of the data storage area (in bytes)
r
../datastorage/chunksize
Size of a data segment (in bytes)
r
../datastorage/size
Size of the data storage area (in bytes)
r
r ... read only
rw ... read and write
* ... parameter only editable, if connection to the Modbus TCP plc is interupted
Applicable services:
Service
Description
../validation_useconnecteddevice
Validate the IO-Link device connected to the IO-Link port
../datastorage/getblobdata
Read the content of the data storage area
../datastorage/stream_set
Transfer an individual data segment
../datastorage/start_stream_set
Start sequential transmission of several data segments
