Diagnostic data
SYS_OBJECTID>
Register
Contents
Bits 8-15
Bits 0-7
30
reserved
Port X01: → Mapping: Diagnostics (→ S. 91)
31
Port X01: Vendor ID
32
reserved
Port X01: Device ID (MSB)
33
Port X01: Device ID
Port X01: Device ID (LSB)
34...39
Port X01: Events (→Mapping: events (→ S. 92))
40
Port X02: Diagnostic data (Mapping: → Port X01 - register 30...39)
50
Port X03: Diagnostic data (Mapping: → Port X01 - register 30...39)
60
Port X04: Diagnostic data (Mapping: → Port X01 - register 30...39)
Legend:
 [Vendor ID]
Vendor ID of the manufacturer of the device on the IO-Link port
2 bytes
0x0000...0xFFFF
 [Device ID]
Device ID of the device on the IO-Link port
Device ID = 0x123456
 Device ID (MSB) = 0x12
 Device ID = 0x34
 Device ID (LSB) = 0x56
3 bytes
per byte: 0x00...0xFF
