IO-Link Master with Modbus TCP Interface DataLine 4 Ports IP 65 / IP 66 / IP 67
91
>
Mapping: Diagnostics
34504
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
reserved
Wrong Length
PD OUT
Wrong Length
PD IN
Cycle time
Wrong
Vendor ID/
Device ID
reserved
reserved
IOL mode
Legend:
 [IOL Mode]
Operating type of the IO-Link port
1 bit
0x0
Other
0x1
IO-Link
 [Wrong Vendor ID/
Device ID]
Verification if the current and configured
vendor ID and device ID are identical
1 bit
0x0
OK
0x1
No match
 [Wrong Cycle Time]
Verification if the current and configured
cycle time are identical
1 bit
0x0
OK
0x1
No match
 [Wrong Length PD IN]
Verification if the size of the received input
data are identical with the configured size
1 bit
0x0
OK
0x1
Configured size too small
 [Wrong Length PD OUT]
Verification if the size of the sent output
data is identical with the size expected by
the IO-Link device
1 bit
0x0
OK
0x1
Configured size too small
