IFM AL1340 - Page 93

IO-Link Master with Modbus TCP Interface DataLine 4 Ports IP 65 / IP 66 / IP 67
93
>
Input Data
34447
Register
Contents
197
Port X01...X04: Digital Input - Pin 2 / Pin 4 (DI) (→ Mapping: digital input data (→ S. 94))
198
Port X01...X04: Diagnostic Information (→ Mapping: diagnostic information (→ S. 94))
199
Port X01...X04: Status Information IO-Link Ports (→Mapping: Status information IO-Link ports (→ S. 95))
200
Port X01...X04: Compact Input Block (4n bytes) (→ Mapping: Compact Input Block (→ S. 95))
Legend:
 [Digital Input - Pin
2 / Pin 4 (DI)]
Digital input data Pin 2 / Pin 4 (operating mode DO) of 4 IO-Link ports
2 bytes
 [Diagnostic
Information]
Diagnostic information
2 bytes
 [Status
Information
IO-Link Ports]
Status information of the IO-Link ports
2 bytes
 [Compact Input
Block (4n Bytes)]
Input data (operating mode IO-Link) of 4 IO-Link ports
n = [2,4,8,16,32]; is determined by parameters [Process Data Length]
(→Configuration Area (→ S. 88))
4n bytes
per byte:
0x00...0xFF
