IFM AL1340 - Page 95

IO-Link Master with Modbus TCP Interface DataLine 4 Ports IP 65 / IP 66 / IP 67
95
>
Mapping: Status information IO-Link ports
34485
Bit
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
res.
res.
res.
res.
X04:
Data
invalid
X03:
Data
invalid
X02:
Data
Invalid
X01:
Data
invalid
res.
res.
res.
res.
X04:
Dev
Not
Conn
X03:
Dev
Not
Conn
X02:
Dev
Not
Conn
X01:
Dev
Not
Conn
Legend:
 [Data invalid]
indicates the status of the process input data on the IO-Link port
1 bit
0x0
data valid
0x1
data invalid
 [Dev Not Conn]
Device Connected: indicates the connection to the device on the IO-Link
port
1 bit
0x0
available
0x1
not available
>
Mapping: Compact Input Block
54567
IO-Link port
Register area
2 bytes/port
(n = 2)
4 bytes/port
(n = 4)
8 bytes/port
(n = 8)
16 bytes/port
(n = 16)
32 bytes/port
(n = 32)
Port X01
200
200...201
200...203
200...207
200...215
Port X02
201
202...203
204...207
208...215
216...231
Port X03
202
204...205
208...211
216...223
232...247
Port X04
203
206...207
212...215
224...231
248...263
