IFM AL1340 - Page 96

IO-Link Master with Modbus TCP Interface DataLine 4 Ports IP 65 / IP 66 / IP 67
96
>
Output Data
34488
Register
Contents
Bits 8-15
Bits 0-7
599
Port X01...X04: Digital Output - Pin 4 (DO) (→ Mapping: Digital output data (→ S. 97))
600
Port X01...X04: Compact Output Block (4n bytes) (→ Mapping: Compact Output Block (→ S. 97))
Legend:
 [Digital Output - Pin 4
(DO)]
Digital output data - pin 4 (operating mode DO) of 4 IO-Link ports
2 bytes
 [Compact Output Block
(4n Bytes)
Output data (operating mode IO-Link) of 4 IO-Link ports
n = [2,4,8,16,32]; is determined by parameters [Process Data
Length] (→Configuration Area (→ S. 88))
4n bytes
per byte:
0x00...0xFF
