IO-Link Master with Modbus TCP Interface DataLine 4 Ports IP 65 / IP 66 / IP 67
98
>
Single Port Access
34444
Register
Contents
Bits 8-15
Bits 0-7
1000
Port X01: Digital Input - pin 2
Port X01: Digital Input - pin 4 (DI)
1001
Port X01: →Mapping: Status information (→ S. 99)
Port X01: →Mapping: PQI (→ S. 99)
1002
Port X01: Input Data IO-Link (n bytes)
1100
reserved
Port X01: Digital Output - pin 4 (DO)
1101
Port X01: Output Data IO-Link (n bytes)
2000
Port X02: Single Port Access (Mapping: → Port X01 - register 1000...1101)
3000
Port X03: Single Port Access (Mapping: → Port X01 - register 1000...1101)
4000
Port X04: Single Port Access (Mapping: → Port X01 - register 1000...1101)
Legend:
 [Digital Input - pin 2]
pin 2 signal level (if used)
1 byte
0x00
LOW
0x01
HIGH
 [Digital Input - pin 4
(DI)]
pin 4 signal level (operating mode DI)
1 byte
0x00
LOW
0x01
HIGH
 [Input Data IO-Link
(n Bytes)]
Input data (operating mode IO-Link) (n bytes)
n = [2,4,8,16,32]; is determined by parameters [Process Data
Length] (→Configuration Area (→ S. 88))
n bytes
per byte: 0x00...0xFF
 [Digital Output - pin
4(DO)]
pin 4 signal level (operating mode DO)
1 byte
0x00
LOW
0x01
HIGH
 [Output Data IO-Link
(n Bytes)
Output data (operating mode IO-Link) (n bytes)
n = [2,4,8,16,32]; is determined by parameters [Process Data
Length] (→Configuration Area (→ S. 88))
n bytes
per byte: 0x00...0xFF
