Rev. 1.0 Page 15
Interconnect:
1. Connect the supplied Transmitter RF Output to the COM-120B’s T/R
Input.
2. Turn the radio to the ON position and set to Channel 2.
3. It is not necessary to connect any audio cables at this time.
The following procedures will lead through the process of:
! Finding an unknown transmitter frequency.
! Frequency Tuning
! Voice Deviation Test
! Squelch test
! CTCSS Tone
! DCS Code
! Squelch Tone Deviation
! DTMF Decode
! Transmit Audio Distortion
1
