Rev. 1.0 Page 8
For the purpose of demonstration, this demo unit has been configured
with software to perform specific setups that coincide with this
document. A description of the test setup is also provided. For
maximum benefit, a kit has been included to allow testing of a radio,
tuning of a filter and measurement of return loss.
The COM-120B provides a powerful set of insturments to allow repair,
calibration and diagnostic evaluations of communications systems. The
COM-120B organizes test functions into screens that can be selected
and altered to perform specific tests. A powerful memory system allows
storage and recall of test setups, frequency lists and test software for
quick evaluation.
Primary Screens:
GEN Test Receivers
REC Test Transmitters
DPLX Simultaneous Transmitter / Receiver test
SPCL Access optional Trunking Features and Tests
Memory Functions:
STORE Store and Label a test setup
RCL Recall a stored test setup
SHOW LIST Access test software
