ICF18, ICF32, ICF40, ICF60, ICF80DZ Cleaning and maintenance
23
ICF18, ICF32, ICF40, ICF60:
➤ Pull the adapter sleeve (A1) off the plug.
➤ Unscrew the screw from the upper part of the housing (A2).
➤ Remove the upper part of the housing from the lower part of the housing
(B1).
➤ Take out the contact pin (B2).
➤ Replace the defective fuse (C1) with a new fuse of the same type and rating
(8A 32V).
➤ Reassemble the plug in the reverse order.
ICF80DZ:
➤ Replace the defective fuse with a new fuse of the same type and rating
(10A).
➤ Proceed as shown in fig. 6, page 7.
6.14 Replacing the light PCB
A
7 Cleaning and maintenance
!
A
NOTICE! Damage hazard
The lamp can only be replaced by the manufacturer, a service
agent or similarly qualified person to avoid hazard.
WARNING! Electrocution hazard
Failure to obey this warning could result in death or serious injury.
Always disconnect the device from the power supply before you
clean and service it.
NOTICE! Damage hazard
• Never clean the cooling device under running water or in dish
water.
• Do not use abrasive cleaning agents or hard objects during
cleaning as these can damage the cooling device.
Igloo ICF18, ICF32, ICF40, ICF60, ICF80DZ_OPM_4445104001_APAC_en_202x-xx-xx.book Page 23 Thursday, September 28, 2023 6:55 PM
