8
Note: Not for metal gates, glass doors or sliding doors.
If you are unsure if your door is suitable, send us web links to
your door pictures to support@igloohome.co
Preparing the Door
Items needed:
Recommended
Door and door frame material : Wood
Recommended
Gap between door and door frame: <3mm (0.01”)
Drill 32mm (1.25”)
Hole Saw
70mm (2.75”)
Hole Saw
20mm (0.78”)
Spade Bit
#2 Phillips Screw Driver 20mm (0.78”)
Chisel
Hammer
135mm
Drill Sheet
