Igloohome Mortise 2+ - Page 9

9
How to use the Drill Sheet
Mark the center of the holes and then drill for accuracy.
Drilling (Door)
Make sure this is
aligned to the centre
of door edge
Door edge
Fold here
before drilling
holes for side
Door edge
120mm (4.72”)
Chiselling
Depth Width:
2 - 3mm
(0.0079” - 0.01”)
