PRODUCT SETUP - GETTING STARTEDFIRECAN™ PARTS
FIRST TIME SETUP:
Ensure the following steps are completed:
1. Using the lid lock, remove lid completely from
FireCan™
2. Remove all items from inside the unit
including the regulator hose.
3. Fold open all foldable legs and place
FireCan™ on a flat, non-flammable surface.
4. Pull back spring collar of Quick-Connect
socket and push on to Quick-Connect stem
attaching the regulator hose to the FireCan™.
5. With the Quick-Connect attached to the
FireCan™, follow the LP SETUP direction on the
next page to connect the regulator hose to the
LP Tank and test for leaks.
TANK PRESSURE:
Minimum Supply Pressure - 5 PSI
Maximum Supply Pressure - 200 PSI
Removable Lid
Lid Lock
Silicone
Handles
Propane Burner
Heat Shield Tray
Flame Screen
FireCan™ Housing
Quick-Connect Stem
Quick-Connect
Socket
Tool-Less
LP Tank Attachment
Adjustable Regulator Valve
Regulator Hose
Foldable Legs
Hose Shield
FireCan™ Portable Fire Pit - Model # IGPRO-00121
2
5
WWW.IGNIK.COMSUSTAINABLE OUTDOOR HEAT
4
3
1
Assembled, Legs Open
12 x 6 x 7.5 in | 30.4 x 15.2 x 19 cm
Assembled, Legs Closed
7.1 x 12.3 x 9.1 in | 18 x 31 x 23 cm
Weight
14.1 lbs. | 6.4 kg
Hose Compatibilty
Inlet - QCC-1 | Outlet - Quick Connect
DIMENSIONS:
Installations must conform with local
codes warning.
WARNING
All LP cylinders to be used with this appliance must be:
• Constructed and marked in accordance with the specifications for LP-gas cylinders
Standard, CAN / CSA B339, Cylinders, Spheres and Tubes for the Transportation
of Dangerous Goods
• Provided with a listed overfilling prevention device.
• Provided with a cylinder connection device compatible with the connector for
outdoor appliances.
• The LP gas cylinder used for this appliance must not have a capacity larger than
20 lb. (9 kg).
• Approximately 18” (46 cm) high & 12” (30 cm) diameter.
• The use of an approved LP gas cylinder stabilizer, must be used when using this
appliance in order to prevent the LP gas cylinder from tipping over.
