30
MAIN TECHNICAL PARAMETERS
AND SPECIFICATIONS
*Actual range may vary depending on Ah of battery rider weight and other riding conditions.
**Electric bike class regulation:
Class 1 - Pedal assist motor with maximum assisted speed 32km/h (20mph)
Class 2 - Pedal assist motor and throttle with maximum assisted speed 32km/h (20mph)
Class 3 - Throttle and/or pedal assist motor with maximum assisted speed 45km/h (28mph)
all classes allow a maximum motor power of 750W(US) or 500W(Canada)
FRAME 6061 Aluminum Hybrid 44.5cm (17.5”)
COLOR Race Red/Silver
FORK SUNTOUR NEX suspension
SHIFTERS SHIMANO 8-speed Rapidre
CHAINRINGS 42T with Narrow Wide teeth
CHAIN KMC X8 EPT
REAR DERAILLEUR SHIMANO ALTUS 8-speed
CASSETTE 8-speed11-34T
HANDLEBAR Alloy ERGOFIT touring bar
GRIPS VELO
STEM PROMAX toolless adjustable threadless
SEAT POST Alloy 30.4mm with quick release (350mm)
SADDLE SELLE ROYAL Nuvola - black
BRAKE LEVERS TEKTRO HD-E350
BRAKE CALIPERS TEKTRO hydraulic disc
ROTORS 180mm
TIRES 700x47C, 28”x1.75” MAXXIS Overdrive
RIMS iGO 700C dual wall alloy
MOTOR 500W geared brushless hi-torque rear hub motor
TORQUE up to 48Nm
CONTROLLER 48V, 18A
BATTERY 3000mAh Cell Lithium-Ion 48V / 12Ah / 576Wh
RANGE 75km (47mi)*
PAS 9 Levels of power assisted pedaling
THROTTLE Any time on demand thumb throttle
SENSOR Electronic 32 pulse Cadence Sensor
CHARGER 110/220V Smart charger, LED status, CUL, 2A
CHARGING TIME 4 to 6 hours
CLASS Class2**
BIKE WEIGHT 23.7kg (52.2 lbs)
BATTERY WEIGHT 3.3kg (7.3 lbs)
WEIGHT CAPACITY 100 kg (220 lbs)
