FRONT PANEL CONTROL
A Menu Button ( )
B Scroll Down / Brightness Button ( )
C Scroll Up / Contrast Button ( )
D Select / Auto Button ( )
E Power Indicator
Green: Normal operation
Orange: Power Management
The monitor enters into power management mode which reduces the power
consumption to less than 2W when receiving no horizontal and/or vertical
sync signal.
F Power Switch ( )
G Speakers
H
AC Connector (AC IN)
I
Audio Connector
J
DVI-D 24pin Connector (DVI)
Available for ProLite E1700S only.
K D-SUB mini 15pin Connector (D-SUB) : ProLite E1700S
Signal Cable for D-SUB Connection (Fixed) : ProLite E1700SV
L Keyhole for Security Lock
8 9
10 11 12
CONTROLS AND CONNECTORS
You can fasten a security lock and cable to prevent the monitor from being removed
without your permission.
