17
Technical Data
Temperature measuring range °C - 50 ... 450
Temperature measurement resolution K 0.1
Accuracy of temperature measurement K
± 0.2 + sensor tolerance PT 1000
DIN IEC 751 Class A
Set temperature resolution K 0.1
Type of control PID
Control deviation (500 ml water in 600 ml glass beaker, mag-
netic stirring bar 40, at 600 rpm, 50 °C)
K ± 0.5
Immersion depth max. mm 200
Supply voltage V DC 8 ... 16 (Limited Power Supply)
Current consumption mA 15
Permissible ambient temperature °C 0 ... 60
Permissible relative humidity % 80
Permissible duration of operation % 100
Protection class according to DIN EN 60529 IP 54
Cable length mm 350
Male connector 6-pin DIN 45322
Socket DIN 12878 Class 2
Dimensions (W x D x H) mm 82 x 22 x 83 (without sensor)
Weight kg 0.2
Subject to technical changes!
Warranty
In accordance with IKA warranty conditions, the warranty period
is 24 months. For claims under the warranty please contact your
local dealer. You may also send the machine direct to our factory,
enclosing the delivery invoice and giving reasons for the claim. You
will be liable for freight costs.
The warranty does not cover worn out parts, nor does it apply
to faults resulting from improper use, insucient care or mainte-
nance not carried out in accordance with the instructions in this
operating manual.
