COMCO IKARUS
Maintenance Manual C42 Series
MaintenanceManual C42-
Series_Issue_VII_18.02.2014.doc
Revison No.:1 15 from 107
- After functionality test secure the Bowden cable with cable and sleeve and
shrink tubing and cut off the supernatant Bowden cable.
III. Electrical Installation:
- Dismantel free temperature sensor at the front left cylinder.
- Mount the temperature switch, move up the sensor cable with abrasion
protection between both left cylinders and push it through the central firewall
aperture.
Figure 13: temperature switch
- In the appropriate place at the pilot’s side drill a hole for the warning light and
mount it.
Figure 14: warning light / actuating lever
- Connect the sensor cable with a cable shoe to the warning light.
- Connect the second port of the warning light with instruments " + ".
- Make functionality test with turned on main switch by removing the sensor
cable from the temperature switch and hold it against mass.
Important The light must be on.
