iKarus C42 Maintenance Manual

COMCO IKARUS
Maintenance Manual C42 Series
MaintenanceManual C42-
Series_Issue_VII_18.02.2014.doc
Revison No.:1 75 from 107
Figure 68: Flattening the safety plate
12) Clean and degrease the covering where the masking tape is attached.
13) Reattach tape.
4.3.5.2 Checking the security of the aileron push-rods
Safety pins are used to secure the rod ends. These can be visually inspected or felt
through the zip openings.
Figure 69: Safety pin at aileron push-rod bellcrank
flattening the
safety plate
Flattened
safety plate
Do not flatten in
plane bending. The
plate could
otherwise break.
pin in rod end
aileron bellcrank
(in wing)

iKarus C42 Specifications

General

Manufacturer	Comco Ikarus
Type	Ultralight Aircraft
Engine	Rotax 912
Cruise Speed	160 km/h
Stall Speed	65 km/h
Seats	2
Height	2.3 m
Maximum Takeoff Weight	472.5 kg
Range	800 km
Service Ceiling	4000 m
Power Output	80 hp
Rate of Climb	5 m/s
