iKarus ECO Piccolo V2 User Manual

14
!
Thank you…
The ECO Piccolo V2 you have bought is a tech-
nically very modern RC electric model helicopter.
Incorporating the latest technology and up-to-date
production processes means excellent performance
and optimum ying times. That means that the Pic-
colo is a helicopter that can also be used outdoors in
relatively calm conditions.
Build the model as carefully as possible.
You will need…
(Not included in kit # 6041001 / 6041002)
Order No.: Description
720535 Piccoboard Plus 35 MHz
720540 Piccoboard Plus 40 MHz
720572 Piccoboard Plus 72 MHz
171201 Micro Servo 201 (2x)
5013002 Transmitter 35MHz
5013003 Transmitter 40MHz
67492 8 cell rechargeable
battery 9.6 V ((NiMH) for about
7 minutes ying time
8023001 Charger for NiMH Batteries110V
8023002 Charger 230 V
2027043 3S LiPo battery 11.1 V 800 mAh
for about 15 minutes ying time
8013006 Charger for Lithium-Polymer
Batteries
Technical data:
Main rotor diameter: 500 mm
Length of fuselage: 500 mm
Flight weight: approx. 280 g
Flight battery: 7 - 12 volts
Tools:
For assembly you will also need
- A sharp knife
- A small pair of ne-nosed pliers
Symbols...
We have used symbols to draw your attention to
certain processes; they mean:
Take special care here!
Use cyanoacrylate (CA-) glue
WARNING!
Cyanoacrylate (CA-) glue sticks skin and eyes within
seconds. Should it come into contact with the eyes,
rinse with water and seek medical help. Must be
kept out of reach of children. Do not breathe in the
vapour. Only use in well-ventilated areas.
Guarantee…
We guarantee for a period of 12 months from the
date of purchase that this kit is free of manufacturing
or material faults. Damage caused by incorrect use
or faulty assembly is not covered by this guarantee.
As soon as the helicopter is taken into use the user
accepts all responsibility resulting from it.
General:
This helicopter is already something special becau-
se of its size. The components have been optimised
for weight and must therefore be handled with care.
Follow the instructions step for step. Before each
step of construction check the parts for moulding
ash and remove it carefully with a sharp knife and
sandpaper.
Always make adjustments immediately when so
instructed. Subsequent rectication is often unne-
cessarily complicated. When glueing very small
amounts of CA glue are sufcient, too much glue
only makes good adhesion difcult. CA glue also
creeps into small gaps so always use it sparingly
and carefully!
All screws in the kit have been optimised for weight
and so are as small as possible. Please be sensitive
when tightening screws. For example the motors
may not be moved by hand any more, but too much
tightening will destroy the thread!
By the way…
The nished Piccolo can be carried easily in the
component case.
IKARUS WISHES YOU LOTS OF FUN FLYING
THE PICCOLO
