IKEA FIXA Manual

FIXA jigsaw
TECHNICAL SPECIFICATIONS
Voltage: Local mains voltage
Mains frequency: Local mains frequency
Power input: 400 W
Stroke rate at no load: 3000 strokes per
minute
Max. sawing depth (wood): 60 mm (2 3/8”)
Max. sawing stroke: 17.5 mm (11/16”)
Bevel cuts (left/right), max.: 45 °
Weight: 1.7 kg (3.75 lb)
Vibration (according to EN 60745-1, EN
60745-2-11):
a
h
,CM.: 19.463 m/s
2
k = 1.5 m/s
2
a
h
,CW.: 15.34 m/s
2
k = 1.5 m/s
2
Noise (according to EN 60745-1):
Noise pressure level Lpa = 88.42 dB (A),
Kpa = 3 dB (A)
Noise power level Lwa = 99.42 dB (A),
Kwa = 3 dB (A)
LIST OF FEATURES
The numbering of the product features
shown refers to the illustration of the
jigsaw on the graphic page.
1. On/Off switch
2. Lock-on button
3. Scale
4. Base plate
5. Guide roller
6. Saw blade (for wood)
7. Holder for guide roller
8. Dust extraction connection
9. Dust extraction adapter
10. Grip
11. Allen key
12. Allen key holder
13. Socket head screws
14. Socket head screws
AREAS OF USE
This jigsaw is intended for making
separating cuts and cut-outs in wood,
plastic, soft metals, ceramic plates
and rubber while resting rmly on the
workpiece. Be sure to choose a saw blade
that is intended for the type of material
you are going to cut. The jigsaw is
suitable for straight and curved cuts with
mitre angles to 45°.
GENERAL SAFETY INSTRUCTIONS
General safety instructions for power
tools
WARNING!
Read all safety warnings and
all instructions. Failure to follow all the
warnings and instructions may result in
electric shock, re and/or serious injury.
Save all warnings and instructions for
future reference.
The term “power tool” in all of the
warnings listed below refers to your mains
operated (corded) power tool or battery
operated (cordless) power tool.
Work area safety
a. Keep work area clean and well lit.
Cluttered and dark areas invite accidents.
b. Do not operate power tools in
explosive atmospheres, such as in the
presence of ammable liquids, gases
or dust. Power tools create sparks which
may ignite the dust of fumes.
ENGLISH 4
