UNIT PARTS
10
For Model: IX5HHEXWS01
(Stainless Steel)
W10297587
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 12992301 Screw
2 12825803 Blade, Fan
3
W10210985 Basepan
4 12990511 Screw
6
W10233569 Tube, Discharge
7
W10280423 Harness, Evap
Heater
8
W10215085 Pan, Drain
9
W10216919 Screw, Shoulder
10 12729129 Evaporator Heater
11
W10174384 Strap, Bale
12 Start Protect,
Combo
W10194431 Production
W10136414 Service
14
12639324SP Thermostat,
Defrost
15
W10206338 Extension, Basepan
17
10835903SP Grommet (4)
18
W10135026 Condenser
19
W10206339 Fastener, Basepan
Extension
20
12225403WD Tray, Drip
21 12990701 Screw
22 12726403 Evaporator
23 Dam
12225702 Right Side
12225602 Left Side
24 12825101 Motor, Fan
25 10428101 Clip, Heater
26
W10234024 Harness, Unit
27
W10143759 Drier
28
W10164016 Compressor Kit
(Contains Items
12, 17, 27, & 29)
29 2264017 Capacitor
30 12477202 Axle, Roller
31
W10189184 Shroud
34 10547003 Clip, Drier
35 12477102 Roller (2)
36 10623002 Clip, Evap (2)
37
W10137529 Grommet (4)
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
5.25 Ozs.
(R−134A)
